Functions at a glance

• For switching and dimming lighting systems that depend on brightness and movement.
• Detection range (for installation height 3 m): circular, 10 m diameter.
• For constant light regulation in combination with Dimmer insert 6524 U-500, 6526 U-500, 6593 U-500 or 6550 U-101-500.
• For heating/air-conditioning/ventilation adjustment in combination with serial insert 6402 U.
• For relay inserts 6401 U-102, 6402 U and 6812 U-101.
• For MOS-Fet insert 6804 U-101.
• For extension insert 6805 U.
• Remote control possible via IR mobile remote control 6010-25.
• Intelligent turn-on delay.
• Surveillance density: 72 sectors with 640 switching segments.
• Switch-off delay: approx. 10 sec - 30 min or short-time pulse 1 sec adjustable.

• Protection class (device): IP 20
• Temperature range (device): 0 °C - 35 °C
• Brightness limit value: 5 Lux
• Detection angle: 360 °

• Mounting height: 2 m - 8 m

• Please order the respective flush-mounted insert separately.
