Functions at a glance

  • The USB/S 1.1 USB interface enables communication between the computer and the KNX system.
  • The data transfer is displayed using the KNX and USB LEDs.
  • The USB interface can be used from ETS 3 V1.0 on.
  • Display elements: LED T: message interchange on the bus, LED K: communication via the interface
  • Protection class (device): IP 20
  • Temperature range (device): -5 °C - 45 °C
  • Storage temperature range: -25 °C - 55 °C
  • Transport temperature range: -25 °C - 70 °C
  • Dimensions: (L x W x D): 90 mm x 36 mm x 61 mm
  • Module width: 2
  • Mounting depth: 68 mm
  • For software and description please check the current Online-Catalogue.
  • 1 MW ≙ 18 mm.
  • Use only in combination with the ETS 3 or PowerProjekt 4.0

    Order details

    Article No.:USB/S1.12
    Order No.:2CDG110243R0021
    EAN:4016779064613
    Customs tariff number:85176200
    Price group:44
    Price:233,00 EUR plus VAT
    Info sheet:Download PDF

    Downloads

    Instruction manual
    Technical manual
    Certificates
    Dimensions
