Functions at a glance

• For activating two 3-speed fans or one 5-speed fan via a multistage or alternating control module.
• It is possible to activate valves or electrical consumers via the available switch outputs.
• The available outputs can be used for activating the 2, 3 and 4 wire fan coil systems with a heating or cooling circuit or with an alternating heating/cooling circuit via the Busch installation bus KNX.
• Force guidance and 4 operating modes can be set for fan and valve.

• Rated voltage: 230 V~, +10 % / -15 %
• Rated frequency: 50 Hz / 60 Hz

• Outputs: 8 Normally open contact, potential free
• Rated current: 6 A

• Protection class (device): IP 20
• Temperature range (device): -5 °C - 45 °C
• Storage temperature range: -25 °C - 55 °C
• Transport temperature range: -25 °C - 70 °C

• Dimensions: (L x W x D): 90 mm x 108 mm x 64 mm
• Module width: 6
• Division units: 4

• For software and description please check the current Online-Catalogue.
• 1 MW ≙ 18 mm.
