Temperature-value transmitter
linear

Take over in my parts list / tender specifications

Functions at a glance

  • For Weather Station 6190/40-101.
  • Serves for converting the measured temperature (-30 to +70 degrees) into electrical signals (0-10 V).
  • Recommended supply lead 3 x 0.25 mm² (max. 100 m)
  • Rated voltage: 24 V-, +8 V / -6 V
  • Protection class (device): IP 65
  • Temperature range (device): -30 °C - 70 °C
  • Dimensions: (L x W x D): 58 mm x 83 mm x 35 mm

    Order details

    Article No.:6190/42
    Order No.:2CKA006190A0032
    EAN:4011395988466
    Customs tariff number:85176200
    Price group:44
    Price:141,00 EUR plus VAT
    Info sheet:Download PDF

    Downloads

    Instruction manual
    Technical manual
    Certificates
    Dimensions
    Temperature-value transmitter 6190/42 Twilight value sensor 6190/44 Brightness-value transmitter 6190/45 (6190/44 and …/45 with window)
    Wiring diagram
