Power pack 24 V
800 mA SELV

Take over in my parts list / tender specifications
Show related products on this page

Functions at a glance

  • Short-circuit-proof, overload-protected and stabilised. Cannot be switched in parallel.
  • Display elements: LEDs green: Status of supply voltage or output voltage
  • Rated voltage: 230 V, +10 % / -15 %
  • Output voltage: 24 V, +1 % / -1 %
  • Rated frequency: 50 Hz / 60 Hz
  • Power dissipation: 5 W
  • Rated current: 800 mA
  • Protection class (device): IP 20
  • Temperature range (device): -5 °C - 45 °C
  • Storage temperature range: -25 °C - 55 °C
  • Transport temperature range: -25 °C - 70 °C
  • Dimensions: (L x W x D): 90 mm x 72 mm x 64 mm
  • Module width: 4
  • Division units: 4
  • Mounting depth: 68 mm
  • 1 MW ≙ 18 mm.

    Order details

    Article No.:6193/33-101
    Order No.:2CKA006149A0021
    EAN:4011395019153
    Customs tariff number:85389099
    Price group:44
    Price:195,00 EUR plus VAT
    Info sheet:Download PDF

    Downloads

    Instruction manual
    Technical manual
    Certificates
    Dimensions
    MDRC devices, measurements 1TE = 18 mm; 2TE = 36 mm; 4TE = 72 mm, 6TE = 108 mm; 8TE = 144 mm; 12TE = 216 mm
