Functions at a glance

• Detection range: rectangular.
• For mounting height of 3 m: frontal toward the detector at a max. of 20 m x 3 m (at a max. of 10 m x 3 m per side). Crosswise toward the detector at a max. of 30 m x 3 m (max. of 15 m x 3m per side).
• With integrated KNX bus coupler.
• Mounting height 27 mm.
• With 4 channels.
• For dimming/brightness of the rules to a defined value in a designated collection area.
• HVAC function for controlling heating and/or cooling systems and ventilation systems in the designated collection area.
• Detectors application with 2 power off stages.
• Detectors application with integrated monitoring function.
• Constant light controller with up to two independent channels.
• Constant light controller with max. 2 outputs for dimming daylight control/rules of two rooflights in the room.
• Integrated object room temperature controller.
• 10 freely programmable IR channels (blue and/or white)
• Incl. 5 logic channels (logic gates, gates, delay and staircase lighting)
• Evaluation via internal brightness sensor.
• Weighting of up to 2 external brightness values ​​and the internal brightness sensor possible.
• The programming button can be activated with the IR transmitter 6010-25 (-500).
• Ceiling mounting on suspended ceilings with spring clamps, on solid ceilings in surface-mounting boxes 6131/39-xxx(-500) or on VDE flush-mounted boxes with intermediate ring for VDE flush-mounted boxes 6131/38-xxx(-500).
• Suitable for false ceilings with a board thickness from 9 to 25 mm.
• Hole size: Ø 68 mm.
• Cannot be installed in British Standard or VDE flushmounted box.
• Recommendation: HaloX^® 100 from Kaiser (article no. 1281-00) with corresponding cover (1281-01 or 1281-61 for exposed concrete) or IBTronic H120-68 from Spelsberg (article no. 97600501).

• Protection class (device): IP 20
• Temperature range (device): -5 °C - 45 °C
• Storage temperature range: -25 °C - 55 °C
• Transport temperature range: -25 °C - 70 °C
• Brightness limit value: 1 Lux

• Dimensions: (L x W x D): 91 mm x 91 mm x 49 mm
• Mounting depth: 22 mm
• Mounting height: 2 m - 4 m

• For software and description please check the current Online-Catalogue.
• HVAC = Heating/ ventilation/air-conditioning
