Top end strip with IR and proximity sensor
Busch-priOn®

Take over in my parts list / tender specifications
Show related products on this page

Functions at a glance

  • Top end strip for installation on 1gang to 3gang support frame (6346/10-101, 6346/11-101 und 6346/12-101).
  • 10 freely programmable IR channels (blue and/or white)
  • Incl. 10 logic channels (light scene actuator, sequence actuator, logic gates, etc.).
  • Protection class (device): IP 20
  • Temperature range (device): -5 °C - 45 °C
  • Storage temperature range: -25 °C - 55 °C
  • Transport temperature range: -25 °C - 70 °C
  • Detection range: frontal: 0.5 m, lateral: 0.5 m
  • Detection range 2:
  • Detection angle: 100 °
  • Dimensions: (L x W x D): 12.5 mm x 106.6 mm x 15.5 mm
  • Mounting height: 1.1 m
  • For software and description please check the current Online-Catalogue.
  • ETS programming only with ETS 3.0f or higher
  • Additional Power-Tool software necessary.

    Order details

    Article No.:6350-825-101
    Order No.:2CKA006310A0156
    EAN:4011395131435
    Customs tariff number:85389099
    Price group:42
    Price:39,00 EUR plus VAT
    Info sheet:Download PDF

    Downloads

    Instruction manual
    Certificates
    Software
    Dimensions
    Top end strip, Busch-priOn® 6348-xxx-101; with IR receiver and proximity sensor 6350-825-101
