Functions at a glance

• For the setup of small and medium-sized network installations.
• For the power supply of up to 3 terminal devices such as IP telephone or IP webcams direct via the network cable.
• For all PoE applications of class 0 to 3, such as IP telephone, IP cameras, WLAN access points or PoE switches.
• External power supply via 8186/04 necessary.

• Protection class (device): IP 20
• Temperature range (device): -5 °C - 45 °C

• Dimensions: (L x W x D): 95 mm x 108 mm x 56 mm
• Module width: 6
• Division units: 6
