My parts list/tender specifications

Actions:

Push-switch
1gang 1way

grey / blue-green
Take over in my parts list / tender specifications
Show related products on this page

Functions at a glance

  • With neutral (transparent) lens.
  • With illumination.
  • SP (operating current),
  • With N terminal.
  • Rated voltage: 250 V~
  • Rated current: 10 A
  • Protection class (device): IP 44
  • Dimensions: (L x W x D): 83 mm x 74 mm x 55 mm
  • Label holder 1763-53.
  • Label holder illuminable with illumination insert 2152 NLI-53.
  • Push switch illuminable by inserting the lamp 8332-1, 8335-1, 8346-1, 8333-1 and 8358.
  • Neon lamp 8346-1 included.
  • For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
  • RAL colour number: Ähnlich 9010

Order details

Article No.:2621 WGL-54
Order No.:2CKA001484A0381
EAN:4011395094761
Customs tariff number:85365080
Price group:12
Price:30,10 EUR plus VAT
Info sheet:Download PDF

Downloads

Certificates
Dimensions
Wiring diagram
Push switch
Push switch with relay (with neon indicator)

Related products

Component
Page 1 of 2
Item was added to the parts list.
Cable entry double closed 2134 W-54
2CKA001761A1507
Cable entry single open 2136 W-54
2CKA001761A1508
Cable bushing adapter plate for coupling several devices 2138 W-54
2CKA001761A1509
Cable entry high design 2139 W-54
2CKA001761A1511
Cable entry 2086 W-54
2CKA001761A1510
Mounting plate 2609 WS
2CKA001716A0042
Label holder 1763-53
2CKA001799A0882
Illumination insert 2152 NLI-53
2CKA001784A0777
Cable entry 2137/10 W-54
2CKA001761A1512
Cable entry 2137/11 W-54
2CKA001761A1513
Symbol for push-switch without symbol 2622 N-101
2CKA001714A0252
Symbol for push-switch light 2622 LI-101
2CKA001714A0260
Symbol for push-switch bell 2622 KI-101
2CKA001714A0278
Symbol for push-switch Red 2622-12-101
2CKA001714A0294
Symbol for push-switch key 2622 TR-101
2CKA001714A0286
Incandescent lamp with connecting cable 8358
2CKA001784A0719
Glow lamp with connecting cable 8346-1
2CKA001784A0321
Incandescent lamp with connecting cable 8335-1
2CKA001784A0529
Incandescent lamp with connecting cable 8333-1
2CKA001784A0024
Glow lamp with connecting cable 8332-1
2CKA001784A0016
