My parts list/tender specifications


Functions at a glance

  • For manual and time-controlled switching of blinds and roller blinds.
  • With dusk to dawn program including (Astro-program)
  • Individual Astro adjustment and Astro blocking time.
  • The controlled devices can be manually operated at any time.
  • Easy adjustment using menu and text-based display.
  • Factory-set switching times can be individually adjusted.
  • Automatic summer/wintertime switch-over
  • Switching times/programme are safely stored in the event of a mains power failure.
  • 4-hour power reserve for time and date (maintenance-free capacitor).
  • Simple toggling between manual/automatic/vacation modes.
  • Control element is adjustable without flush-mounted insert.
  • 2 switching times per day can be user-defined for each day of the week.
  • Astro switching times and switching times can be combined.
  • For basic blind insert 6418 U.
  • Temperature range (device): 0 °C - 35 °C
    • See respective cover plates 6435-xx.

      Order details

      Article No.:6456
      Order No.:2CKA006410A0374
      Customs tariff number:85389099
      Price group:20
      Info sheet:Download PDF
